GO KART CHEETAH 6

Cheetah 6 Specifications

Engine Information

• EPA certificated

• Engine type: 4-stroke, single

cylinder, air cooled, Horizontal OHV

Engine

• Displacement: 163cc, 5.5HP

• Max HP: 3.2KW/3600RPM

• Max torque: 10.8NM/2800RPM

• Bore x stroke: 2.67x1.77inches

• Max speed: 24 mph

• Climbing ability: 12 degrees

• Starting system: Electric or Pull

• Battery: YTX12-BS,12V 10Ah

• Carburetor brand: P19

• Engine oil: SAE 10W-40

General Information

• Clutch: Automatic torque converter

CVT with reverse

• Driveline / Driving wheel: Chain /

Dual wheel drive

• Suspension F / R: Double A-arm /

swing-arm

• Brake: Rear disc

• Tires, F / R: 145/70-6 /16*6-8

• Wheel: Steel

• Fuel capacity: 1 gal

• Weight, G.W. / N.W.: 308 / 264 lbs

• Max load: 180 lbs

Dimension Information

• Wheelbase: 43.7 inches

• OA L x W x H: 63x36x50 inches

• Height to seat: 14.2 inches

• Min ground clearance: 3.6 inches

• Pedal to seat back distance: 28” to

32”

• Packing size: 60X32X21 inches

www.bvpowersports.com

Key features:

• Sporty stylish design

• Adjustable seat: pedal to seat back adjustable from 28” to 32”, Age Group: 6-12 yrs,

fits person up to 5’4”

• 4 point safety seat belt

• Remote Start/Kill

• Speed Governor

• Manual choke

• LED headlight

• Electric start with pull start backup

• Fully automatic with reverse, 5.5 HP horizontal OHV engine

• Bikini sunshade top

• Rack and pinion steering wheel

• Hydraulic rear disc brake

• Max speed 25 m/h

• Parking brake
